Bộ hiển thị nhiệt độ 40005E Masibus Viet Nam
40005E Masibus
The 40005E is an Enhanced version of our Legacy model 40005 Bargraph indicators, additional capabilities have been added by way of multi-serial ports, Ethernet port, scanning speed, and Relay outputs. The model is available in single channel and dual channel format.
Configuration
40005E is configured using the front keyboard and display or PC based configuration software supplied with unit. The unit has a 4 digit numeric and 101 segment Bars to display process Value, Alarm/Trip and communication status are displayed by discrete LEDs on front fascia.
Communication
40005E comes with one RS485 port as a standard, a second RS485 port and/or a Ethernet Port are options to enhance the communication capabilities of the unit and use it as an RTU, controller or protection device for parameters like Level, Vibration, Gas detection, etc.
Control or Alarm
The optional 4 or 8 Relay outputs can be freely mapped to any channel set points and configured as control, Alarm or Trip functionality with FailSafe or Normal Logic. Any one relay can also be configured as a watchdog output.
Re-Transmission
An isolated 4-20mA Re-Transmission output option is available for onward transmission to PLC/ DCS/ Recorder/ SCADA
Enclosure
40005E is housed in a 144X72 mm extruded Aluminum enclosure with a IP55 front fascia, all cards are plug-in and Input/Output connections are via multi-pin connector and pre-fab cables.
Features
Micro controller based
Full 4 digit numeric & 101 segment bar display
Universal Input
Square root extractor
Fully configurable & programmable by front keypad or PC based configuration software
Digital calibration
Built-in Transmitter supply
Watchdog output
Power Supply, Input & Output Isolated for 1500VAC
Options:
Redundant RS485 serial port
Retransmission output (Isolated)
Ethernet (Modnet) port
4/8 Relay Output
Applications
Monitoring of Level, Vibration, Flow, etc
Alarm/Trip Unit
On/off Controller
Digital Switch
Gas Detection
Marine-Utility Monitoring on Ships
