SP (industrial)

SP (industrial)

ATMF8000IL-SP ATMF8000IS-SP

Insertion (IS) Inline (IL)

> ¼ 2 < 40″ (50-1000mm)(IS)

IL <392°F(200°C) IS 158°F (70°C) remote

Displays numerical and graphical Calibration milliwatts (mw) for ongoing diagnostics, limited Ex approvals

Analog, Modbus Compliant RS485 RTU communications

CE, DC Powered: CSA C22.2, UL1604, Atex Ex nA IIC T4, and Class I, Div 2, Grps BCD T4″; “DC and AC

 SD (portable)

SD (portable)

ATMF8000IL-SD ATMF8000IS-SD

Insertion (SD)

> 1 < 40″(25-1000mm) (IS)

200°F(93°C), >158°F(70°C) remote

Datalogger Keypad configuration, 10 hour rechargeable battery

Up to 3800 data points in .csv format (Excel® file), via USB cable

CE

 SX (ATEX/CSA/FM)

SX (ATEX/CSA/FM)

ATMF8000IL-SX ATMF8000IS-SX

Insertion (IS) Inline (IL)

> ¼ 2 < 40″ (50-1000mm)(IS)

IL <392°F(200°C) IS 158°F (70°C) remote

Displays numerical and graphical Calibration milliwatts (mw) for ongoing diagnostics, Europe/North American Ex approvals

Analog, Modbus Compliant RS485 RTU communications

CE and ATEX Zone I,II 2 G Ex d IIB+H2 T6 Gb

 SC (Nonhazardous)

SC (Nonhazardous)

ATMF8000IL-SC ATMF8000IS-SC

Insertion (IS) Inline (IL)

> ¼ 2 < 40″ (50-1000mm)(IS)

IL <392°F(200°C) IS 158°F (70°C) remote

Low cost, no display, Nema 4X Enclosure

RS232, 4-20mA for Flow, 0 – 5 VDC for Temperature, Pulse for Total

CE

 ALTS (liquid/gas flow/level switch)

ALTS (liquid/gas flow/level switch)

ALTS

Insertion (IS) Inline (IL)

> ¼ 2 <40″ (50-1000mm)(IS)

IL <392°F(200°C) IS 158°F (70°C) remote

Used for both for signal or dual flow or level switch for either gases and liquids

Single or dual contact switch

CE/FM/CSA
