Đồng hồ đo áp suất 63-3133 MATHESON Vietnam

Specifications

• Dial Size: 2-1/2″
• Pressure Connection: 1/4″ MNPT – Lower Mount
• Bourdon Tube Material: Copper alloy
• Pressure Connection Material: Copper alloy
• Case: Polished brass
• Window: Twist-lock clear polycarbonate
• Operating Temperature: -40°F to 140°F (-40°C to 60°C)
• Accuracy Class: +/- 3/2/3% of span (ASME B40.100 Grade B)

Working pressure
Steady: 3/4 of full scale value
Fluctuating: 2/3 of full scale value
Short time: full scale value

Ordering Information

Part Number	ALT-P/N	Model	Range
SEQ633106	MGAG-0027-BA	63-3106	0-15 psig (acetylene)
SEQ633115	MGAG-0030-BA	63-3115	0-15 psig
SEQ633131	MGAG-0033-BA	63-3131	0-30 psig
SEQ633104	MGAG-0026-BA	63-3104	-30″-0-30 psig
SEQ633161	MGAG-0038-BA	63-3161	0-60 psig
SEQ633109	MGAG-0097-BA	63-3109	-30″-0-60 psig
SEQ633112	MGAG-0028-BA	63-3112	0-100 psig
SEQ633112A	MGAG-0606-BA	63-3112A	-30″-0-100 psig
SEQ633122	MGAG-0031-BA	63-3122	0-200psig
SEQ633107	MGAG-0098-BA	63-3107	-30″-0-200 psig
SEQ633142	MGAG-0035-BA	63-3142	0-400 psig
SEQ633113	MGAG-0029-BA	63-3113	0-1000 psig
SEQ633123	MGAG-0032-BA	63-3123	0-2000 psig
SEQ633133	MGAG-0034-BA	63-3133	0-3000 psig
SEQ633143	MGAG-0036-BA	63-3143	0-4000 psig
SEQ633153	MGAG-0037-BA	63-3153	0-5000 psig
SEQ633175	MGAG-0039-BA	63-3175	0-7500 psig
