Hollow shaft diameter (mm)

Datasheet PDF (357 KB)

6mm – 15 mm

Schutzart

IP65 ohne Dichtungsring
IP67 mit Dichtungsring

Max. speed rpm

with oil seal 6000 rpm 1, continuous
without oil seal 12000 rpm 1, continuous

Max. load capacity of the shaft

40 N axial, 80 N radial

Flange

Different types and mounting options (see data sheet)

Operation temperature

-40 °C … +85 °C

Output circuit

RS422, Push-Pull

Materials

Hollow shaft stainless steel
Housing aluminium alloy

Shock resistance

50 G / 11 ms

Vibration resistance

10 G / 10 – 2000 Hz

Connection options

1.5 m cable ( customized cable length available, please send us your request)
M12 5 pin
M12 8 pin
M23 12 pin
