FILTER (17) SF17-800-M3DC /F00017G00054 Shavo

Shavo Vietnam,FILTER (17) SF17-800-M3DC /F00017G00054 Shavo

FEATURES

Shavo’s Designer Series Large Flow Range general purpose Filter removes upto 99% of the liquid water
Design of the filter elements gives both surface and depth filtration for cleaner air
Ideally suited for header lines and large flow rated tools and cylinder operations

MODEL SF17

Parameters	Specifications
Pipe Threads	G 1, 1 ¼, 1 ½ Parallel (F) – Standard
Filter Element Size	5, 25, 40 * micron
Element Material	Plastic (Polypropylene)	– Standard
	Sintered Bronze	– Optional
Body Material	Al. Alloy die-cast
Bowl Material	Al. Alloy Metal with sight glass – Standard
Maximum Inlet Pressure	with Metal Bowl Manual Drain	: 250 psig (17.5 bar)
	with Metal Bowl Automatic Drain and Semi-Automatic Drain	: 150 psig (10.5 bar)
Maximum Operating Temperature (ambient)	80ºC (175º F)
Standard Nominal Flow Rate at 87 psi (6 bar) supply pressure and 14.5 psi (1 bar) pressure drop	G 1	880 scfm (415 dm³/sec) CV (16.60)
	G 1 ½	880 scfm (415 dm³/sec) CV (16.60)
Drain	Manual – Standard Automatic – Optional Sem-Automatic – Optional

+ Values indicated are with 40 micron elements, with finer elements these values will be lower.

100% India Origin	Shavo Vietnam	Code: B00001G00081 Description: FIL/REG11-4SN-201M-M6KA-NS. INSTRUMENT FILTER/REG WITH S.S.TRIM,1/4″,RELI EVING STD.KNOB (WITH GUAGE),METALLIC (70cc)-STD.,MANUAL DRAIN,5 MICRON (SINT.BRONZE),0.70 TO 7.00 KG/SQ.CM,MAIN PORTS NPT/GAUGE PORTS BSPT,NITRILE,CUSTOMERS SPL. MOUNTING BRACKET, 11-4SN-201M-M6KA-NS.
100% India Origin	Shavo Vietnam	Code: F00017G00054 Description: FILTER (17) SF17-800-M3DC SHAVO MAKE,FILTER ,(17 SERIES),SIZE 1″,STANDARD,WITH MANUAL DRAIN,WITH 50 MICRONPLASTIC F ILTERELEMENT,METAL BOWL WITH SIGHT GLASS,THR EAD BSP, SF17-800-M3DC
