*Accuracy | < 2% of FS range | Analysis | 0-1%, 0-5%, 0-10%, 0-25% FS ranges |
Application | % Oxygen analysis in hydrocarbon, H2, (CO2) & mixed gas streams | Approvals | meets UL standard for Cl 1, div 1, Group C,D |
Area Classification | Enclosure Class 1, Division 1, Groups B, C, D
NEMA4/7 | Alarms | 2 adjustable form C relay contacts non-latching;
sensor and power failure |
Calibration | Certified gas of O2 balance N2 approximating
80% of range above analysis range recommended for optimum results | Compensation: | Temperature |
Connections | 1/8″ or 1/4″ compression tube fittings | Controls | Explosion proof actuators for range selection,
zero and span calibration adjustments |
Display | 3-1/2 digit bright red LCD; resolution .001% | Enclosure | Painted aluminum 16x18x11” wall mt., 70 lbs. |
Flow Sensitivity | None between 1-5 SCFH, 2 SCFH recommended | Linearity | > .995 over all ranges |
Pressure: | Inlet – 5-30 psig, max 150 psig; vent – atmospher not to exceed +/- 14″ water column | Power | Specify 100/120 or 220/240 VAC |
Response Time | 90% of final FS reading < 10 seconds | Sample System | Flow meter with integral valve |
Sensitivity | < 0.5% of FS range | Sensor Model | GPR-11-32-4 |
sensor Life | 36 months in air at 25ºC, 1 atm | Signal Output | 4-20mA isolated and 0-1V |
Temp. Range | -10º to 45ºC (GPR), -20º to 45ºC (XLT sensor) | Warranty | 12 months analyzer; 12 months sensor |
Wetted Parts | Stainless steel | | |
