Solid Front Safety Pattern

Pressure Gauge

GS Range

• Nominal Diameter options of 100mm, 150mm St.St. case

• Nominal Diameter 125mm Phenolic case

• Degree of Protection IP55/IP65.

• Blowout Protection.

• Ranges up to 4000bar

• Monel pressure connection, material and options available.

• ATEX II 2 G/D option Performance characteristics

Enclosure options

• IP55 Protection for non filled

• IP65 Protection for filled

Pressure Connection Material

• 316 Stainless Steel as standard Dials

• White Aluminium with black graduation

Process connection

• 1 /2-14 NPT, G1/2B or 5/8“-18 UNF, M16 x 1.5 for high pressure applications

Accuracy

• Model GS 1.0 per EN 837·1:1998 , 0.6 optional

Ambient temperature

• -30 to +60 °C non fluid

• +10 to +60 °C glycerine filled

• -30 to +60 °C silicone fluid filled

Process temperature

• -30 to +250 °C non fluid

• +10 to +80 °C glycerine filled

• -30 to +120 °C silicone fluid filled

• +10 to +150 °C (ranges 2500/4000 bar)
