For Grounding in Hazardous Areas
- Aircraft refueling
- Chemical plants
- Grain elevators
- Rescue and Hazmat operations
- These reels bond and/or ground aircraft, fuel trucks, and other equipment.
- Provide smooth operation and require minimum cable pull.
- Declutching arbor and adjustable guide arm with cable guide.
- Optional stainless steel construction of spool, frame, and ratchet system available.
- Standard finish is oven-cured enamel.
- Manual rewind version also available.
- Available with 1/8″, 7×19 galvanized carbon steel cable.
- 100 amp alligator clamp.
- Stainless steel or plastic-covered cable and “Y” branches available at additional charge.
- Cable guide arm of cast aluminum and ZA12 alum zinc alloy.
BASE MODEL | CAPACITY OF REEL | APPROX. WEIGHT | |||
Hose/Cable Size | ft. | m | lb. | kg. | |
| HGR50 | 3/16 vinyl coated | 75 | 22.9 | 28 | 12.7 |
| MHGR50 | 3/16 vinyl coated | 125 | 38.1 | 18 | 8.2 |
| HGR100 | 3/16 vinyl coated | 100 | 30.5 | 37 | 16.8 |
