KH-DN80-SAE210/420 M-282A Zn MHA ZENTGRAF Vietnam

Liên hệ

Đại lý MHA ZENTGRAF Vietnam,KH-DN80-SAE210/420 M-282A Zn MHA ZENTGRAF Vietnam,MHA ZENTGRAF Vietnam,KH-DN80-SAE210/420 M-282A Zn MHA ZENTGRAF,KH-DN80-SAE210/420 M-282A Zn, Ball valve / 2/2-Wege- Flanschkugelhahn 2/2-way flanged ball valve

Đại lý MHA ZENTGRAF Vietnam,KH-DN80-SAE210/420 M-282A Zn MHA ZENTGRAF Vietnam

KH-DN80-SAE210/420 M-282A Zn, Ball valve / 2/2-Wege- Flanschkugelhahn 2/2-way flanged ball valve

Flange ball valve with SAE connection metric / UNC KH-SAE Steel

AVAILABLE SIZES

DN15 – DN80 (5/8“ to 3“)

CONNECTIONS

ISO 6162-1 and -2 (double flange pattern)

ACCESSORIES ON REQUEST

• Locking devices • Actuators • Mounting holes • Position switches • Combinations • Detent

GENERAL DIMENSIONS

KH-DN15 15 75 35 88 88 31 13 160 12 – 132 Al

KH-DN20 20 80 35 98 100 36,5 14 200 14 103 – Zn

KH-DN25 25 88 38 118 113 39,5 14 200 14 116 – Zn

KH-DN32 32 100 50 145 158 68 17 320 17 167 – Al

KH-DN40 38 110 55 165 178 78 17 320 17 187 – Al

KH-DN50 48 116 58 198 210 94 17 320 17 219 – Al

KH-DN65 63 170 75 218 275 100 20 600 16 – – St(1)

KH-DN80 (PN100) 76 170 70 248 307 111 26 600 19 – – St(1)

KH-DN80 (PN160/420) 76 170 79 258 315 114,5 26 600 19 – – St(1)

KH-DN15-SAE210/420 17,5 38,1 M8 18 40,5 18,2 M8 18 2,96

KH-DN20-SAE210/420 22,2 47,6 M10 18 50,8 23,8 M10 18 4,20

KH-DN25-SAE210/420 27,8 57,2 M12 20 52,4 26,2 M10 20 6,00

KH-DN32-SAE210/420(2) 30,2 58,7 M12 20 66,7 31,8 M14 22 11,65

KH-DN32-SAE210/420 30,2 58,7 M10 20 66,7 31,8 M12 22 11,70

KH-DN40-SAE210/420 35,7 69,9 M12 21 79,4 36,5 M16 27 17,10

KH-DN50-SAE210/420 42,9 77,8 M12 20 96,8 44,5 M20 28 24,60

KH-DN65-SAE210/420 58,7 123,8 M24 41 88,9 50,8 M12 19 44,40

KH-DN80-SAE210/420 71,4 152,4 M30 47 106,4 61,9 M16 24 54,90

KH-DN80-SAE210/420 71,4 152,4 M30 47 106,4 61,9 M16 24 60,40

KH-DN15-SAE210/420 17,5 38,1 5/16“UNC 18 40,5 18,2 5/16“UNC 18 2,96

KH-DN20-SAE210/420 22,2 47,6 3/8“UNC 18 50,8 23,8 3/8“UNC 18 4,20

KH-DN25-SAE210/420 27,8 57,2 7/16“UNC 20 52,4 26,2 3/8“UNC 20 6,00

KH-DN32-SAE210/420 30,2 58,7 7/16“UNC 22 66,7 31,8 1/2“UNC 22 11,70

KH-DN40-SAE210/420 35,7 69,9 1/2“UNC 20 79,4 36,5 5/8“UNC 24 17,10

KH-DN50-SAE210/420 42,9 77,8 1/2“UNC 20 96,8 44,5 3/4“UNC 28 24,60
