Proton Vietnam,Máy đo đường kính laser một trục InteliSENS DG1060-MKII / DG1060-i4 /00054MC003 Proton

InteliSENSTM DG1000 Series

Dòng máy đo đường kính quét laser InteliSENSTM DG cung cấp tốc độ nhanh, chính xác và có thể lặp lại
các phép đo đối với các sản phẩm được sản xuất trong giới hạn dung sai tới hạn. Thiết kế VIỆT nghiệp mạnh mẽ
đảm bảo hoạt động đáng tin cậy trong môi trường sản xuất khó khăn nhất. Thiết kế nhỏ gọn
và việc sử dụng thiết bị điện tử Xử lý tín hiệu kỹ thuật số tiên tiến làm cho các đồng hồ đo này cực kỳ dễ dàng tích hợp.
Đầu đo có RS232 và CANbus theo tiêu chuẩn; Profibus là một tùy chọn có sẵn.
Tương tự và đóng tiếp điểm được cung cấp trong các đơn vị PSU-RS2-AR và CS2G tùy chọn.
Các hệ thống điều khiển dòng NEXiSTM này cho phép kiểm soát quá trình chính xác và hiệu quả về chi phí cho các nhà sản xuất
dây, cáp, ống, đường ống và nhiều vật liệu được sản xuất liên tục khác.

LỢI ÍCH

600 lần quét mỗi giây (Tùy chọn lên đến 1400)
Đo lường không tiếp xúc
Nhiều chế độ đo
Loại bỏ lỗi đo lường của người vận hành
100% kiểm tra chất lượng
VIỆT nghệ DSP tiên tiến
Không bị ảnh hưởng bởi tốc độ và độ rung
Khả năng chống bụi bẩn tuyệt vời
Thiết kế nhỏ gọn, mạnh mẽ
Bảo vệ IP65, NEMA4
Cảm biến thông minh

VIỆT NGHỆ

Thời gian quét (ST) là một chức năng của
Vận tốc quét (SV) và
Kích thước cổng (GS). ST = GS SV

Thời gian quét (ST) là một chức năng của
Vận tốc quét (SV) và
Kích thước cổng (GS). EP1 = SV x T1

Vị trí cạnh (EP2) đang được quét
Vận tốc (SV) x Thời gian T2 EP2 = SV x T2

Kích thước sản phẩm OD = EP2 – EP1 or (T2-T1)

THÔNG SỐ KỸ THUẬT

Model DG1030 DG1060 DG1100

Kích thước cổng 30mm (1.181inch) 60mm (2.362inch) 100mm (3.937inch)
Kích cỡ nhỏ nhất 0.1mm (0.004inch) 0.2mm (0.008inch) 0.5mm (0.0197inch)
Kích thước tối đa 27mm (1.063inch) 57mm (2.244inch) 100mm (3.937inch)
Độ chính xác: 0,008% 0.001mm (0.00004inch) 0.0015mm (0.00006inch) 0.002 mm (0.00008″)
Tỷ lệ đo lường 290 x 66 x 170mm 425 x 68 x 212mm 504 x 68 x 230mm
