New-Cosmos Vietnam,Máy dò khí XP-3318 New-Cosmos
Model
XP-3368II-W / XP-3368II / XP-3318II
Target Gas
Combustible gas and solvent gas, Oxygen
Detection Principle
Combustible gas and solvent gas : Catalytic, Oxygen : Galvanic
Sampling Method
Extractive
Weight
Approx. 460g (including batteries)
Features
Convert to 32 types gas’s concentration*
Robust design
Wide range models
Up to five combustible gases can be set as target gas (option)
Selectable power supply: alkaline AA batteries / rechargeable nickel metal hydride AA batteries
Timer and stopwatch function
*Only for XP-3318II and XP-3368II-W
Specifications
Sampling Method | Extractive | |
Alarm Method | Gas Alarm | Beeping with flashing red light and AL icon on the LCD |
Device Error | Beeping with flashing yellow light and error message on the LCD | |
Power Source | ･Non-rechargeable alkaline AA battery x4: Toshiba LR6, Panasonic LR6X, Duracell MN1500, Energizer E91 or Varta 4106 | |
Operating Temperature/Humidity | -20 to 50℃ 95%RH. No condensation | |
Compliance*1 | ATEX: Ex II 1G Ex ia da IIC T4 Ga*1 | |
Ingress Protection | IP67 | |
Main Features | Self-diagnosis (sensor error), Zero adjustment, Battery level indication, Flashlight, Peak-hold, LCD backlight, Audio alarm muting during gas alarm, Time indication, Alarm test, Alarm volume change, Audio muting | |
Dimensions | W91 x H164 x D44mm | |
Mass | Approx. 460g (including batteries) | |
Accessaries | Gas sampling tube(1m), Shoulder strap, Drain filter, Filter element, Alkaline AA batteries(or Rechargeable nickel metal hydride AA batteries) x 4, Screen protector film x 3 | |
Multi Gas Detector
Model | XP-3368II-W | XP-3368II | XP-3318II | |||
Target Gas | Combustible gas | Oxygen | Combustible gas | Oxygen | Combustible gas | Oxygen |
Detection Principle | Catalytic | Galvanic cell | Catalytic | Galvanic cell | Catalytic | Galvanic cell |
Mesuring Range | 0.0–100.0%LEL (100.1–110.0%LEL) | 0–25vol% | 0–5000ppm or | 0–25vol% | 0–100%LEL | 0–25vol% |
Accuracy*2 | ≤ 1000ppm : ±100ppm | ±0.3vol% | ≤10%F.S. : ±2.5%F.S. | ±0.3vol% | ±5%F.S. | ±0.3vol% |
Resolution | 0.1%LEL or 1ppm | 0.1vol% | 1ppm | 0.1vol% | 0.1%LEL | 0.1vol% |
Alarm Set Value | 20%LEL | 18vol% | 250ppm or 500ppm | 18vol% | 20%LEL | 18vol% |
Response Time | T90: 30 seconds | ー | T90 : 30 seconds | ー | T90 : 30 seconds | ー |
Continuous Operation Time*3 | Approx. 15 hours | |||||
100% Japan Origin | New-Cosmos Vietnam | Code: XP-3318Ⅱ |
