ORT Series

Economically viable price, convenient method of use!

ORT Series provides two variable output channels and one fixed output channel with regulated DC Power Supply. Select the ORT Series if you want to output power easily.

	Supply of low price DC Power Supply
	CV / CC mode operation
	Stable Ripple & Noise
	INDEPENDENT / SERIES / PARALLEL MODE

	Our company offers ORS Series that is priced low and that is easy to use by leveraging accurate and optimal power supplier technology and that offers clean voltage and current. Moreover, this is a DC power supplier that can be trusted unlike other companies¡¯ products.
	We adopted FND Display that is characterized by small size, convenient frontal display design, devoid of space limitations and that is comforting to the eyes. Enjoy it at low price.

Specification

	ORT-183	ORT-185	ORT-303	ORT-305
Output Rating	0~18V, 0~3A, 2ch	0~18V, 0~5A, 2ch	0~30V, 0~3A, 2ch	0~30V, 0~5A, 2ch
Output Rating	5V/1A Fixed Output	5V/1A Fixed Output	5V/1A Fixed Output	5V/1A Fixed Output
Resolution	100mV / 10mA	100mV / 10mA	100mV / 10mA	100mV / 10mA
Read-back Accuracy (@25¡É ±5¡É)±(%of output + offset)
Voltage	0.4% + 2dgt	0.4% + 2dgt	0.4% + 2dgt	0.4% + 2dgt
Current	0.4% + 2dgt	0.4% + 2dgt	0.4% + 2dgt	0.4% + 2dgt
Ripple & Noise	¡Â 2mVp-p ¡Â 2mArms	¡Â 2mVp-p ¡Â 2mArms	¡Â 2mVp-p ¡Â 2mArms	¡Â 2mVp-p ¡Â 2mArms
Load Regulation
Voltage	0.1% + 20mV	0.1% + 20mV	0.1% + 20mV	0.1% + 20mV
Curren	0.1% + 5mA	0.1% + 5mA	0.1% + 5mA	0.1% + 5mA
Line Regulation
Voltage	0.1% + 20mV	0.1% + 20mV	0.1% + 20mV	0.1% + 20mV
Curren	0.1% + 5mA	0.1% + 5mA	0.1% + 5mA	0.1% + 5mA
Voltage Programming Speed(No load)
Rising time	¡Â 100ms	¡Â 100ms	¡Â 100ms	¡Â 100ms
Falling time	¡Â 1.2s	¡Â 1.2s	¡Â 1.2s	¡Â 1.2s
Common matters	Dimension : 130mm(W) x 165mm(H) x 310mm(D) Power Cord, User Manual, Output Cable provided
