The REMOTE PILOT BOX (RPBiD) are plastic pilot boxes to be used with our SERIAL SOLUTIONS. It can control from 2 to 6 pneumatic valves. The electronics inside is resin bonded and protected from attack by external agents. Thanks to the reduced size, the tool is extremely robust, compact and easily adaptable to any kind of tank.
The modularity and versatility pairing with the device ECOSERIAL are the ideal solution for any type of filtration system with a large number of valves, since they eliminate the considerable cost of the electrical connections.
| Main Features | Features | Values |
|---|---|---|
| Dimensions | External Dimensions ( L x H x W mm ) | 305x65x72 |
| Protection | Protection Level (standard) | IP66, TYPE 4X |
| Temperature | Working Temperature (°C) | -10… +60 |
| Power Supply | Power Supply Range (standard) | 12..30Vdc from MASTER |
| Power Consumption | 7W | |
| Outputs | Coils Control Voltage | 24Vdc |
| Functions | Cyclic Management | ok |
| System | Type | SLAVE |
| Maximum number of coil | 12 | |
| Type of control driver | BUS |
