XXXSYSECPI Position indicator,

-proximity switch for synchronizing process and program

– tough design

– high switch distance

– max. ambient temperature range: -25 to 230°C (-13 to 446°F)

– simple mounting with mounting plate

– separate junction box

Switching distance max. 20 mm (0.79 in.) positioned to steel St37 , sized 50 mm in square (2.16 in. in square)

Temperature range position indicator: -25 to 230°C (-13 to 446°F) junction box: -25 to 70°C (-13 to 158°F)

Protection rate IP67

Length of cable 5 m (15 ft)

Output No. 2: active 24 V / 300 mA max. short circuit protected

Junction Box

-Pin 2 (brown cable): + 24 VDC ( 7 to 40 VDC), ripple max. 15 %

-Pin 3 (black cable):

-Pin 1 (blue cable): 0 V
