Rosemount Vietnam, Pressure Transmitter 1151DP3S22L4 Rosemount

Rosemount 1151 Pressure Transmitter

• Proven field performance and reliability • Commitment to continuous improvement • Reference accuracy of 0.075% • Two-year stability of 0.1% • Rangeability of 50:1

Output

• 4-20 mA dc; 10-50 mA dc

• Smart 4-20 mA dc, 4-20 mA dc square root of input with adjustable damping (Flow)

Range

• 0-5″ H2O to 0-1000 psid

Accuracy

• SMART: +/-0.1% of calibrated span

• Analog: +/-0.2 to +/-0.25% of calibrated span

Materials

• Isolating Diaphragms: 316L SST, Hastelloy C, Monel, Tantalum Process Flanges

• Adapters: Cadmium and Nickel plated CS, 316 SST, Hastelloy C, Tantalum

Features

• Installed Stability: ± 0.01% of URL for 2 years

• Protocols available include 4-20mA HART, Analog, and Low Power

• Differential, gauge and absolute pressure measurements

• Pressure ranges up to 6000 psi
