Rated Capacity (R.C.)

kgf/tf

1,2,3,5,10,20,30,50,100,200tf

Rated Output (R.O.)

mV/V

2.0 ± 0.005

Zero Balance

mV/V

0 ± 0.02

Accuracy Class

A

B

Combined Error

%

0.02

0.05

Repeatability

%

0.01

0.02

Creep (30 min)

%

0.03

0.03

Temperature effect on

Zero Value

% / 10℃

0.03

0.03

Output Value

% / 10℃

0.03

0.03

Excitation

Recommended

V

10

Maximum

V

15

Resistance

Input

Ω

350±3.5

Output

Ω

350±3.5

Insulation

MΩ

>2,000

Compensated temperature range

℃

-10 ~ +40

Operating temperature range

℃

-30 ~ +80
