MAGNETIC TYPE SPEED RELAY

Overspeed and Slip Detection
Rated speed
: 80rpm to 1800rpm
: 33m/min. to 300m/min.
Actuating speed 60rpm (Minimum setting speed)

Speed Relay is a mechanical type motion sensor for monitoring operation speed of belt conveyors, cranes, crushers, etc., and operates when speed of the machine shaft becomes the setting speed. Since the microswitch in Speed Relay is mechanically turned ON or OFF by induction torque generated by rotation of the permanent magnet, the power supply is not necessary. Besides, the maintenance is easy.

Speed relay ESRW-102, ESRW-122, ESRW-302 Matsushima
