Industrial RTU 2M NVRAM 64M DRAM

ST-IPM-6350 Redlion Việt Nam

Specifications

Performance Specifications

• Industrial PowerPC (32 bit data bus)

• Operating system: embedded LINUX

• Dynamic memory (RAM): 16+ Megabytes – 32bit; 0 wait states

• Program memory (Flash): 16+ Megabytes

• Datalogging memory NVRAM: 2 MB (battery-backed)

• Maximum local I/O: 640

• Datalogging support: Sixnet® Sixlog

• IEC 61131 programming: Sixnet ISaGRAF

• High Level C programming: LINUX open software

Ethernet Ports (All)

• 10/100BaseTx (auto-detecting)

• Connection: RJ45 (auto-crossover)

• Protocols: TCP/IP, ARP, UDP, ICMP, DHCP, Modbus/TCP, Sixnet and more

• Independent networks: 2 w/ unique MAC and IP addresses

• Network port 1: (1) shielded RJ45 connector

• Network port 2: (4) shielded RJ45 connectors (linked via integrated industrial Ethernet switch)

Serial Port

• Up to 115,200 baud

• RS-232 Port A RJ45 (TD, RD, CTS, RTS, CD,TR, DSR, GND)

• RS-232 Port B RJ45 (TD, RD, CTS, RTS, CD, DTR, DSR, GND)

• RS-485 Port C Screws (485+, 485-, GND) (2-wire half-duplex)

• Protocols (master or slave): Sixnet and Modbus RTU/ASCII; many others available in LINUX

• Flow control – hardware, software, half/full-duplex modem

Environmental

• DIN-rail or flat-panel mount

• Input power: 10-30 VDC

• Input current: 150 mA @ 24 VDC (typical)

• Temperature: -40 to 70°C (-40 to 85°C storage)

• Humidity: 5% to 95% RH (non-condensing)

• Flammability: UL 94V-0 materials

• Electrical Safety: UL 508, CSA C22.2/14; EN61010-1 (IEC1010); CE

• EMI emissions: FCC part 15, ICES-003, Class A; EN55022; EN61326-1; CE

• EMC immunity: EN61326-1 (EN61000-4-2,3,4,6); CE

• Vibration: IEC68-2-6

• Hazardous locations: UL 1604, CSA C22.2/213, (Class 1, Div 2, Groups A,B,C,D) Cenelec EN50021 Zone 2

• MTBF ST-IPm-6350: 2,003,287 Hours GB @ 40°C per MIL-HNDBK-217F2

• Marine/offshore tested and/or verified to meet various marine and maritime standards

Software

SX-1131-S-1K – ISaGRAF Open Workbench for up to 1K I/O

SX-1131-S-256 – ISaGRAF Open Workbench for up to 256 I/O

SX-1131-S-32 – ISaGRAF Open Workbench for up to 32 I/O

SX-1131-S-BIG – ISaGRAF Open Workbench for Unlimited I/O

SXIPM-AGA-1 – IPm® Add-on Application-AGA Gas Flow Calc.

SXIPM-DNP3-1 – IPm® Add-on Application-DNP3 Add-On

SXIPM-IEC870-1 – IPm® Add-on Application-IEC870-5-101/104 Slave Driver

SXIPM-PPP – IPm® Add-on Application-PPP

SXIPM-SAFE – IPm® Add-on Application-IP Security

SXIPM-SNMP – IPm® Add-on Application-SNMP

SXTOOLS-2 – SIXNET® Tool Kit-Level 1 Plus 1 Feature Set

SXTOOLS-3 – SIXNET® Tool Kit-Level 1 Plus 2 Feature Sets

SXTOOLS-4 – SIXNET® Tool Kit-Level 1 Plus 3 Feature Sets

SXTOOLS-P – SIXNET® Tool Kit Package for IPm® Plus
