PRODUCT DESCRIPTION
- Use in the carpet, denim, technical textile and modern home textile industries
- More robust design and increased roller diameter than the standard ELSTRAIGHT version
- Reduction of the web throughput time to a minimum, thereby reducing the response time via a more compact design
- System also offers the required accuracy and force for extremely high web tensions
TECHNICAL SPECIFICATIONS
| Sensors | 4–8 matrix cameras |
| Angular resolution | 0.5 degrees |
| Straightening mechanism | |
| Actuating travel for skew correction | ±600 mm with 3 skew rollers |
| Actuating travel for bow correction | ±300 mm with 3 curved rollers |
| Roller diameter | 168 mm |
| Type of web | Carpet, denim, technical textiles |
| Web width | 1500-5000 mm |
| Web speed | 1-150 m/min |
| Web tension | 100-4000 N |
| Ambient temperature | +10 °C to +50 °C |
| Operating voltage | 3×400 V, 50/60 Hz |
| Current consumption | 12 A |
