Accuracy: | | ±0.1% of full scale |
Sampling rate: | | 7,000 Hz |
Power: | | AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low. |
Battery life: | | Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use |
Capacity x Resolution: | | 200 x 0.05 lbF, 3200 x 1 ozF, 100 x 0.02 kgF, 1000 x 0.2 N, 1 x 0.0002 kN |
Outputs: | | USB / RS-232: Configurable up to 115,200 baud. Automatic output available up to 250 Hz. Includes Gauge Control Language 2 for full computer control.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VDC, ±0.25% of full scale at capacity
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines. |
Safe overload: | | 200% of full scale (display shows “OVER” at 110% and above) |
Warranty: | | 3 years (see individual statement for further details) |
