GPR-2600 SERIES % OXYGEN ANALYZER

Features an advanced galvanic oxygen sensor capable of measuring oxygen concentrations ranging from 0.05% to 100% over a 36 month operating life with no periodic maintenance required, menu driven controls, integral flow meter, and, a full range of analog outputs. Optional temperature control enhances stability.

Accuracy:	< +1% of FS range under constant conditions	Analysis:	0-1%, 0-5%, 0-10%, 0-25% FS ranges; auto-ranging or manually lock on single range
Application:	Oxygen analysis from 0.05% to 100% in inert, helium, hydrogen, mixed and acid (CO2) gas streams	Approvals:	CE
Area Classification:	General purpose	Alarms:	2 adjustable form C relay contacts non-latching; “weak sensor” indicator; power failure; system failure
Calibration:	Ambient or compressed air on0-25% range; or certified span gas of O2balance N2approximating 80%of analysis range or one range higher than analysis range	Compensation:	Barometric pressure and temperature; optional temperature controlled heated sample system
Connections:	1/4″ compression tube fittings	Controls:	Water resistant keypad; menu driven range selection, calibration, alarm and system functions
Data Acquisition:	Selectable data point intervals	Display:	Graphical LCD 5 x 2.75; resolution .001%; displays real time ambient temperature and pressure
Enclosure:	Painted aluminum 7.5” x 10.8” x 12.25” panel mount	Flow Sensitivity:	None between 1-5 SCFH, 2 SCFH recommended
Linearity:	> .995 over all ranges	Pressure:	Inlet – regulate to 5-30 psig, max 100 psig; vent – atmospheric
Power:	Universal; specify 110 or 220 VAC with optional heater	Range ID:	1-5V output with 1V representing the lowest range
Recovery Time:	Air to < 0.1% in < 30 seconds on N2purge	Response Time:	90% of final FS reading < 10 seconds
Sample System:	Wetted parts: corrosion resistant materials, stainless steel optional, includes flow meter with integral metering valve	Sensitivity:	< 0.5% of FS range
Sensor Model:	GPR-11-32-4 – requires no maintenance	Sensor Life:	36 months inair at 25ºC and 1 atm
Signal Output:	4-20mA isolated and 0-1V	Temp. Range:	-10º to 45ºC (GPR sensor); -20º to 45ºC (XLT sensor)
Warranty:	12 months analyzer; 12 months sensor
