- Sealless design
- Extremely low maintenance
- Recognition of the phase change by turbidity or colour
- Easy selection of the right model due to fix pathlengths
- Easy configuration and system integration
The PhaseGuard monitors interface changes of turbidity or colour. Three models of the PhaseGuard cover the possible applications: interface switching for turbidity (model T), for colour (model C), for high turbidity (model HT). The PhaseGuard is factory adjusted with a universal measuring range based on absorption. For simple applications and system integration the instrument configuration and communication can be easily done using the serial interface in combination with the existing outputs. For a more comfortable installation and operation the optional control unit SICON with touch screen technology and colour display can be connected.
Wavelength turbidity | LED 880 nm |
Wavelength color | LED 430 nm |
Measuring principle | Absorption |
Nominal range | 0 .. 100 % Absorption |
Resolution | 0.5 % Absorption |
Installation | In-line housing Varivent® or compatible |
Enclosure | Stainless steel 1.4301 |
Protection | IP66 |
Sample temperature | -10 .. +100 °C |
Pathlength | 10 mm (models T & C)
5 mm (model HT) |
Outputs | 1 x 4 .. 20 mA
2 x Open-Collector Transistor |
Pipe diameter | ≥ DN 40 (modells T & C)
≥ DN 65 (model HT) |
Supply voltage | 9 .. 30 VDC |
Power input | < 2 W (with Profibus DP: < 3 W) |
Sample pressure | ≤ 1 MPa (10 bar) @ 100 °C |
Interfaces | Profibus DP or Modbus RTU (option) |
Ambient environment | -10 .. +50 °C / 0 .. 100 % RH |
Cleaning | CIP/SIP compatible up to 120 °C @ 2h |
Material sensor head | Stainless steel 1.4404 |
Windows material | Sapphire |
Configuration | USB Interface and parameter file |
Colour in Process Water / Waste Water
| Lowest measuring range | 0-0.05 E ColorPlus / 0-100 % PhaseGuard |
| Highest measuring range | 0-3 E ColorPlus / 0-100 % PhaseGuard |
| Applications in | Chemical / Pharmaceutical Industry |
| Petrochemical Industry / Refinery |
| Power Plants |
| Pulp / Paper Industry |
Concentration of Milk Fat
| Highest measuring range | 0-5% |
| Applications in | Dairy Industry |
Leakage of Glycol from Cooling Circuit
| Highest measuring range | 0-100% |
| Applications in | Emission Monitoring |
Phase Separation Beer / Water
| Highest measuring range | 0-100 % |
| Applications in | Brewing Industry |
Phase Separation Fruit Juice / Water
| Highest measuring range | 0-100 % |
| Applications in | Soft Drink / Fruit Juice Industry |
Phase Separation Milk / Water
| Lowest measuring range | |
| Highest measuring range | 0-100 % |
| Applications in | Dairy Industry |
Phase Separation Sea Water / Fish Water (red)
| Highest measuring range | 0-100 % |
| Applications in | Fishing Industry |
Phase Separation Water / Wort
| Highest measuring range | 0-100% |
| Applications in | Brewing Industry |
Phase Separation Wine / Water
| Highest measuring range | 0-100 % |
| Applications in | Wine Industry |
Phase Separation Yeast / Beer
| Highest measuring range | 0-100 % |
| Applications in | Brewing Industry |
Turbidity after Lauter Tun
| Lowest measuring range | 0-1 EBC |
| Highest measuring range | 0-1000 EBC |
| Applications in | Brewing Industry |
Turbidity at Separator
| Highest measuring range | 0-100 % |
| Applications in | Brewing Industry |
| Wine Industry |
Turbidity for KG Dosing
| Lowest measuring range | 0-1 EBC |
| Highest measuring range | 0-1000 EBC |
| Applications in | Brewing Industry |
| Wine Industry |
Turbidity in Treated Fishery Waste Water (Effluent)
| Highest measuring range | 0-100 % |
| Applications in | Fishing Industry |
| Industry | Measuring Point |
|---|
Brewing Industry | Phase Separation Beer / Water
Phase Separation Water / Wort
Phase Separation Yeast / Beer
Turbidity after Lauter Tun
Turbidity at Separator
Turbidity for KG Dosing |
Chemical / Pharmaceutical Industry | Application undisclosed
Colour in Process Water / Waste Water |
Dairy Industry | Concentration of Milk Fat
Phase Separation Milk / Water |
Emission Monitoring | Leakage of Glycol from Cooling Circuit |
Fishing Industry | Phase Separation Sea Water / Fish Water (red)
Turbidity in Treated Fishery Waste Water (Effluent) |
Petrochemical Industry / Refinery | Colour in Process Water / Waste Water |
Power Plants | Colour in Process Water / Waste Water |
Pulp / Paper Industry | Colour in Process Water / Waste Water |
Soft Drink / Fruit Juice Industry | Phase Separation Fruit Juice / Water |
Wine Industry | Phase Separation Wine / Water
Turbidity at Separator
Turbidity for KG Dosing |
