| Rated load (R.L.): | 300, 500, 750, 1000, 1500, 2000, 3000, 5000 Kg |
| Combined error: | < ±0,017% of R.O. |
| Repeatability: | < ±0,015% of R.O. |
| Creep (20 minutes): | < ±0,016% of R.L. |
| Safe overload: | 150% of R.L. |
| Maximum overload: | 200% of R.L. |
| Recommended input: | 5÷15 Vdc/Vac |
| Input resistance: | 400 ± 20 Ohms |
| Output resistance: | 350 ± 3 Ohms |
| Insulation resistance: | > 5000 M Ohms |
| Rated output (R.O.): | 2±0.1% mV/V |
| Zero balance: | < ±2% of R.O. |
| Temperature range: | -20 ÷ +50°C |
| Compensated temperature range: | -10 ÷ +40°C |
| Temperature effect on zero balance: | < ±0.010% of R.O./5°K |
| Temperature effect on output: | < ±0.006% of output/5°K |
| Max load deflection: | 0.2÷0.4 mm |
| Precision class: | 3000 n. OIML |
| Degree of protection: | IP68 |
| Electrical connection: | 6 conductors shielded cable; length 6 m |
| Clamping force without any load: | 300÷2000 kg : 136 Nm 3000÷5000 kg : 205 Nm |
